Engineered for extreme environments, these high-temperature carbon fiber sheets utilize advanced bismaleimide resin chemistry to maintain mechanical properties at elevated temperatures. The thermally stable matrix resists degradation in continuous high-heat applications while providing excellent wear resistance. Perfect for aerospace components, semiconductor processing equipment, and high-performance automotive applications. Complete material certification including outgassing data available.
| Parameter | Specification | Test Method |
|---|---|---|
| Resin System | Bismaleimide | ASTM D3171 |
| Continuous Service Temp | 300°C | ASTM E831 |
| Peak Temperature | 350°C (short term) | ASTM E831 |
| Tg (Dry) | 310°C | DMA @ 1Hz |
| Coefficient of Friction | 0.15 | ASTM D1894 |
| Wear Rate | 2×10⁻⁶ mm³/N·m | ASTM G99 |
| Outgassing | <0.5% TML, <0.1% CVCM | ASTM E595 |
| Vacuum Compatibility | Yes | NASA STD 6001 |
| Panel Sizes | Up to 1500×1500mm | ISO 2768-1 |
Engineered for extreme environments, these high-temperature carbon fiber sheets utilize advanced bismaleimide resin chemistry to maintain mechanical properties at elevated temperatures. The thermally stable matrix resists degradation in continuous high-heat applications while providing excellent wear resistance. Perfect for aerospace components, semiconductor processing equipment, and high-performance automotive applications. Complete material certification including outgassing data available.
